ready-to-build configurations
All the parts you need are included in these configurations.
Individual parts
Simply assemble your desired configuration yourself. The combination possibilities are almost limitless. Your only limit is the rack width.
0.5U cover for USW-Enterprise-8-PoE – 19″ rackmount
0.5U cover for USW-Enterprise-8-PoE - 19" rackmount (0.5U height)
With this rackmount you can keep order in your network rack. A holder holds the devices securely on the base plate, so they do not slip.
ATTENTION:
- As the device becomes very hot during operation, this rackmount is printed exclusively with ASA material
- The white color of the ASA material does not match the white color of the PETG material from which the rackmounts are normally made
More detailed description see below
Select options
This product has multiple variants. The options may be chosen on the product page
incl. VAT
zzgl. Versandkosten
1.5U adapter for 1U base plates
With this adapter, 1U base plates can be integrated into a 1.5U rack configuration. Please note that the width of the 1U base plate must be selected when ordering. The total width of the adapter is calculated from the ordered configuration + 20mm additional width.
Example: If the 1U base plate has a width of 94.00mm, then the 94.00 configuration must be ordered. The adapter plate therefore has a total width of 94.00mm + 20.00mm = 114.00mm
Select options
This product has multiple variants. The options may be chosen on the product page
incl. VAT
zzgl. Versandkosten
10″ Switch Lite 16 – 0.5U Cover V2
Select options
This product has multiple variants. The options may be chosen on the product page
incl. VAT
zzgl. Versandkosten
10″ Universalmount
10″ Universalmount (Kopie)
New
19″ rackmount adapter – Tenda TEG1024D
19" rackmount adapter - Tenda TEG1024D
The Tenda TEG1024D can be integrated into a 19" rack with this adapter.
Select options
This product has multiple variants. The options may be chosen on the product page
incl. VAT
zzgl. Versandkosten
19″ Ubiquiti UVNR-Instant – Rackmount 2U
Ubiquiti UVNR-Instant - 19" rackmount (height 2U)
With this rackmount you can keep order in your network rack. A holder holds the devices securely on the base plate, so they do not slip.
More detailed description see below
Select options
incl. VAT
19″ Universalmount (small) Configurator
Configure your 19" 1U rackmount with the Universal Rackmount as base.
Attention: The configuration Universalmount + 2x RaspberryPi Mount is only recommended if the Raspi's are powered via POE.
The device is fixed to the rackmount by means of a flexibly adjustable mounting system.
Scope of delivery:
- Universal rackmount with mounting system
- Incl. Mounting material
- your additionally configured components
Additional mounting material: (not included in delivery - can be ordered separately)
- 2x M6 rack rails screw
- 2x M6 rack rails nut
Suitable for devices with the following size:
- Maximum device dimensions: (width x depth x height) 140x182x40mm
- Minimum device dimensions: (width x depth x height) 100x72x1mm
The delivery takes place without the illustrated devices. The illustration of the devices is for illustration purposes only.
19″ USG+Switch8 conversion kit
Conversion kit to turn 1x base plate USG & 1x base plate Switch8 into a 19" rackmount (like here: 19" USG&Switch8 Rackmount)
Conversion kit consisting of:
- 1x connector
- 2x sidemount
Select options
This product has multiple variants. The options may be chosen on the product page
incl. VAT
zzgl. Versandkosten
1x HDD – 3.5″ – base disk
3.5" HDD - Baseplate
A 3.5" HDD can be seamlessly integrated into the modular system from drei-d-w.de with this base plate.
There is an open and a closed version.
- Open: Hard disk with connections oriented to the front
- Closed: Hard disk with connections oriented to the rear
Key Facts
- Dimensions: The base plate has a width of 134.00mm and a height of 1U.
- Compatibility: Perfectly suited for the modular system from www.drei-d-w.de to design your network infrastructure modularly and individually.
Select options
This product has multiple variants. The options may be chosen on the product page
incl. VAT
zzgl. Versandkosten
